Ce Certificate Heavy Loading Pipe Belt Conveyor for Mining Coal Power Plant

group name: Pipe Belt Conveyor

Min Order: 1 set

brand name: SKE

model: KP

Nearest port for product export: Shanghai,China

Delivery clauses under the trade mode: FOB, CIF, EXW

Acceptable payment methods: T/T, L/C, Westem Union

update time: Mon, 15 Nov 2021 15:05:06 GMT

contact supplier

Paramtents

color customized
material features heat resistant, fire resistant
applications chemical industry, mining transport, power plant

Packging & Delivery

Min Order1 set

Briefing

The pipe belt conveyor is a kind of special belt conveyor developed on the basis of the trough belt conveyor.

Detailed

Ce Certificate Heavy Loading Pipe Belt Conveyor for Mining Coal Power Plant

The KP Pipe Conveyor Systems is also known as the pipe belt conveyor system. SKE is a pipe belt conveyor manufacturer in China. We can make bulk materials conveyed in an enclosed and environment friendly conditions come true and protect from leakage, spilling, dust, mixed debris, rain, and snow.

Advantages

1.Conveying bulk material in a closed working condition

2.Long distance conveying and large curvilinear bending

3.It is able to move material in a large angle easily

4.No deviation of round tube pipe belt conveyor

5.Transporting bulk materials in both directions

6.Meet the needs of material conveying in different scenarios

Application

The KP Pipe Belt Conveyor is a special type of conveyors developed on the basis of the through belt conveyor. We usually use six idlers to form a regular polygon idler group to force the conveyor belt to form a circle.

Industries: It is able to be widely used in thermal power plant, building materials, chemical industry, metallurgy, mining, coal, ports, grain and other industries.

Materials: Coal, coke, coal ash, metal ores (gold, silver, copper, iron, lead, zinc, etc.), ore powder, sinter ore, non-metallic ores (marble, basalt, limestone, granite, potash, trona, salt, phosphate, etc), alternative fuel, slag, gravel aggregate, fertilizer, grain (soybean, corn, wheat) ,etc.

Methods: The pipe belt conveyor can be divided into unidirectional and bidirectional conveyors, of which the unidirectional material transportation can be subdivided into two types of one-way pipe forming and two-way pipe forming.

Tech Datasheet

Specifications of KP pipe conveyor system
Pipe diameter(dp/mm)	Belt Width(b/mm)	Belt pipe conveyor systems belt speed v/(m/s)
Pipe diameter(dp/mm)	Belt Width(b/mm)	0.8	1.0	1.25	1.6	2.0	2.5	3.15	4.0	4.5	5.0
100	430	17.0	21.2	26.5	33.9	—	—	—	—	—	—
150	600	38.0	47.5	59.4	76.0	95.0	118.8	—	—	—	—
200	750	66.5	83.1	103.9	133.0	166.2	207.8	—	—	—	—
250	1000	117.9	147.4	184.3	235.8	294.8	368.5	464.3	—	—	—
300	1100	141.1	176.4	211.7	282.2	352.8	441.0	555.7	705.6	—	—
350	1300	—	237.6	297.0	380.2	497.2	594.0	748.4	950.4	1069.2	1188.0
400	1600	—	388.8	486.0	622.1	777.6	972.0	1224.7	1555.2	1749.6	1944.0
500	1900	—	558.1	697.6	893.0	1116.2	1395.3	1758.0	2232.4	2511.5	2790.5
600	2250	—	777.6	972.0	1244.2	1555.2	1944.0	2449.4	3110.4	3499.2	3888.0
700	2550	—	1008.0	1260.0	1612.8	2016.0	2520.0	3175.2	4032.0	4536.2	5040.2
850	3100	—	1454.4	1818.0	2327.0	2908.8	3636.0	4580.0	5817.6	6544.8	7272.0
